Siklu Multi-Mode Module SFP 10G AX-SFP+10G-MM These Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA)1. They are simultaneously compatible with Gigabit Ethernet as specified in IEEE Std 802.32 and Fibre Channel FC- PI-2 Rev. 5.03. They are RoHS compliant and lead-free per Directive 2002/95/EC4 and Finisar Application Note AN-2038. Digital diagnostics functions are available via the 2-wire serial bus specified in the
Up to 10Gb/s bi-directional data links Hot-pluggable SFP footprint Built-in digital diagnostic functions 850nm Oxide VCSEL laser transmitter Duplex LC connector RoHS Compliant and Lead-Free Up to 500m on 50/125µm MMF, 300m on 62.5/125µm MMF Metal enclosure, for lower EMI Single 3.3V power supply Low power dissipation Industrial operating temperature range: -40°C to 85°C
