Informações do Produto

LCD Display Backlit screen shows detailed wire map, pin configuration, and test results clearly PoE Detection Identifies PoE (Power over Ethernet) presence and voltage on network cables Cable Types Supported RJ45 (Ethernet), RJ11 (telephone), and coaxial cables Wire Mapping Detects open circuits, shorts, miswires, reversals, and split pairs Cable Tracing Includes probe (tone tracer) for locating cables through walls or bundles Remote Unit Enables testing of cables over distance (e.g., installed runs) Tone Generator Built-in tone signal for cable tracking with the included probe Auto-off Function Conserves battery life when not in use Specifications Display: LCD Signal: Analogue/Digital Mode Frequency: 455KHz Tracking a Cable in the Working Network: Yes Tracking BNC Cable: No (But Can Use Alligator Clip) Scan Range: ≤600m Display: R&M; 1-8/G (LCD) Max. Range: 300m Cable Type: CAT5, CAT5e, CAT6 Range: 2.5m~200m Wire Continuity Ω: No Telephone Line POL +/-: No Flashlight: Yes Non-Contact Voltage Detection (NCV): Yes Input Protection: DC 60V Transmitter Battery: 3.7V 1400mAh Li-ion Receiver Battery: 3.7V 1400mAh Li-ion Charging Type: USB Type-C Duration of Tracing: >10h Transmitter Dimensions: 125 × 70 × 32mm Receiver Dimensions: 198 × 50 × 28mm Identification: CE RoHS: Yes Storage Bag: Yes
